RAVENOL SCR PAO 32 Screw Kompressorenöl is full synthetic compressoroil with ISO VG Class 32, which is specifically designed to provide effective lubrication in rotary screw air compressors.
RAVENOL SCR PAO 32 Screw Kompressorenöl is also specifically designed to significantly extend service life in rotary screw compressors.
RAVENOL SCR PAO 32 Screw Kompressorenöl has excellent resistance to oxidative breakdown caused by exposure to air at high discharge temperatures it has excellent thermal stability for reducing carbon deposit formation.
RAVENOL SCR PAO 32 Screw Kompressorenöl shows good protection against wear, protects against rust and corrosion. Low volatility reduces oil carry-over into the air system. Reduces fluid consumption.
The full benefits of a change to RAVENOL SCR PAO 32 Screw Kompressorenöl will only be realized by minimizing contamination with the previously used oil. Certain makes of compressors do not permit completedraining, so if the drained oil is heavily oxidized (shown by significant increase in the oil’s total acid number and viscosity), recharging with RAVENOL SCR PAO 32 Screw Kompressorenöl may not result in optimum performance and fluid service life.
RAVENOL SCR PAO 32 Screw Kompressorenöl has excellent oxidation stability, corrosion, deposit control and low volatility and provides up to 8,000 hours of continuous worry-free service for lubrication, sealing and effective heat removal for efficient compressor performance.
Application Note
RAVENOL SCR PAO 32 Screw Kompressorenöl is recommended for use in rotary screw air compressors.
While RAVENOL SCR PAO 32 Screw Kompressorenöl is fully compatible with most mineral and synthetic compressor fluids, it should not be mixed or contaminated with fluids containing polyalkylene glycols or silicones.
Characteristics
- High oxidation stability.
- Excellent protection against rust and corrosion.
- Excellent resistance to oxidative breakdown caused by exposure to air at high discharge temperatures
- Higher thermal stability reduces carbon deposit formation.
- Improved viscosity index and good low temperature properties.
- Good protection against wear.
- Protects against rust and corrosion.
- Low volatility reduces oil carry-over into the air system.
- Reduces fluid consumption.
Карактеристике
| Параметар | Вредност | Надгледање |
|---|---|---|
| Ширина, mm | 580 | |
| Дужина, mm | 580 | |
| Висина, mm | 885 | |
| Тежина, kg | 191.509 | |
| Вискозност | 32W | |
| Brand | RAVENOL | |
| Густина на 20°Ц, g/cm³ | 839 | EN ISO 12185 |
| Боја | Светло жуто | visual |
| Вискозност на 100°C, mm²/s | 6 | DIN 51562-1 |
| Вискозност на 40°C, mm²/s | 30.9 | DIN 51562-1 |
| Индекс вискозности VI | 142 | DIN ISO 2909 |
| Тачка стињавања, °C | -69 | DIN ISO 3016 |
| Температура паљења, °C | 250 | DIN EN ISO 2592 |
| Киселински број, ТАН, mgKOH/g | 0.15 | ASTM D664 |
| Одвајање воде, ml/54°Cmin | 40-40-0 (5) | ASTM D1401 |
| Формирање пене И на 24°Ц, ml/ml | 0/0 | ASTM D892 |
| Формирање пене ИИ на 93,5°Ц, ml/ml | 0/0 | ASTM D892 |
| Формирање пене ИИИ од 24°Ц до 93,5°Ц, ml/ml | 0/0 | ASTM D892 |
| Испитивање корозије бакра, на 100°Ц/3х | 1a | ASTM D130 |
| Рђање (корозија) А – дестилована вода | положио | ASTM D665 |
| Рђање (корозија) Б – синтетичка морска вода | положио | ASTM D665 |
| Губитак испаравањем % теж. | < 0.1 | ASTM D524 |
