RAVENOL Kompressorenoel PAO VDL 100 is a premium quality compressor oil of the ISO VG Class 100, which is specially designed to extend the service life time of compressors
RAVENOL Kompressorenoel PAO VDL 100 contains additives, which ensure an excellent wear protection and protects against residue and corrosion (both steel and non-ferrous metal). Most compressors have to work under high temperature so that the used oil has to have a good aging resistance but also a low residue building.
In addition RAVENOL Kompressorenoel PAO VDL 100 conforms to its ISO VG Class and shows a remarkable low evaporative behavior an outstanding demulsifying power as well as excellent air separation ability. It ensures certain lubrication not only in the high temperature range but also in cold condition of the compressor to reach a wear minimisation. By the use of selected and matched additives the tendency of coking and flammable residues is minimized.
Application Note
RAVENOL Kompressorenoel PAO VDL 100 is recommended for all compressors especially in rotary screw air compressors.
Characteristics
- High oxidation stability.
- Excellent protection against rust and corrosion.
- Best wear protection. Keeps compressor components free of sludge and varnish to ensure trouble free operation and lower maintenance costs on fluid change-out.
- Very low evaporative behavior and an outstanding demulsifying power
- Excellent air separation ability.
- Better resistance to oxidative breakdown.
- Extends oil change intervals up to 8.000 hours service in rotary screw compressors and 1.000 hours service in rotary vane compressors.
- Improves compressor operating efficiency, lower energy consumption costs by reducing of oil thickening.
Карактеристике
| Параметар | Вредност | Надгледање |
|---|---|---|
| Ширина, mm | 255 | |
| Дужина, mm | 295 | |
| Висина, mm | 370 | |
| Волатилност NOACK, % | 2.54 | ASTM D5800 |
| Тежина, kg | 192.757 | |
| Вискозност | 100 | |
| Brand | RAVENOL | |
| Густина на 20°Ц, g/cm³ | 866 | EN ISO 12185 |
| Боја | Жута | visual |
| Вискозност на 100°C, mm²/s | 14.1 | DIN 51562-1 |
| Вискозност на 40°C, mm²/s | 100.7 | DIN 51562-1 |
| Индекс вискозности VI | 143 | DIN ISO 2909 |
| Тачка стињавања, °C | -27 | DIN ISO 3016 |
| Температура паљења, °C | 263 | DIN EN ISO 2592 |
| Киселински број, ТАН, mgKOH/g | 0.11 | ASTM D664 |
| Одвајање воде, ml/54°Cmin | 41-39-0 (10) | ASTM D1401 |
| Формирање пене И на 24°Ц, ml/ml | 10/0 | ASTM D892 |
| Формирање пене ИИ на 93,5°Ц, ml/ml | 0/0 | ASTM D892 |
| Формирање пене ИИИ од 24°Ц до 93,5°Ц, ml/ml | 0/0 | ASTM D892 |
| Испитивање корозије бакра, на 100°Ц/3х | 1a | ASTM D130 |
| Рђање (корозија) А – дестилована вода | положио | ASTM D665 |
| Рђање (корозија) Б – синтетичка морска вода | положио | ASTM D665 |
| Губитак испаравањем % теж. | < 0.1 | ASTM D524 |
